Khoom Paub meej:

Khoom npe:	Cov ntaub ntub dej npog pwm
Lub teb chaws ntawm keeb kwm:	Taizhou, Zhejiang, Suav teb
Hom Tshuaj:	YIDIAN
Core/Cav:	2083,2344,2311,2316,2738,S136
Cavity naj npawb:	kev cai
Pwm loj / hnyav:	Nws nyob ntawm koj qhov khoom loj
Guarantee:	1 xyoos (tsis muaj teeb meem tib neeg tsim)
Txoj kev them nyiaj:	T/T,L/C

Khoom feature:

Lub rooj vag kaw lus hais txog ib feem ntawm cov neeg khiav dej num ua ntej cov yas nkag mus rau hauv cov kab noj hniav ntawm lub nozzle, nrog rau cov neeg khiav dej num tseem ceeb, cov khoom siv txias txias, cov neeg khiav dej num thiab lub rooj vag.

Lub rooj vag kaw lus, tseem hu ua qhov kev sib tw khiav, yog cov txheej txheem pub noj uas ua rau cov yas yaj ntawm lub nozzle ntawm lub tshuab txhaj tshuaj mus rau kab noj hniav. Nws yog ncaj qha ntsig txog molding zoo thiab ntau lawm efficiency ntawm cov khoom yas.

Mainstream

Nws yog ib qho kev nkag mus rau hauv cov pwm uas txuas qhov txhaj tshuaj nozzle ntawm lub tshuab txhaj tshuaj molding mus rau qhov khiav los yog kab noj hniav. Sab saum toj ntawm lub sprue yog concave rau kev koom tes nrog lub nozzle. Lub inlet txoj kab uas hla ntawm lub ntsiab channel yuav tsum yog me ntsis loj dua li txoj kab uas hla ntawm lub nozzle (0.8mm) kom tsis txhob overflow thiab tiv thaiv ob tug los ntawm kev thaiv vim tsis raug kev twb kev txuas. Txoj kab uas hla ntawm qhov nkag yog nyob ntawm qhov loj ntawm cov khoom, feem ntau 4-8mm. Txoj kab uas hla ntawm lub sprue yuav tsum tau nthuav dav sab hauv ntawm lub kaum sab xis ntawm 3 degree mus rau 5 degree los pab txhawb kev tso tawm ntawm cov khib nyiab khiav.

txias slug

Nws yog kab noj hniav nyob rau hauv qhov kawg ntawm lub ntsiab channel los ntes cov khoom txias uas tsim los ntawm ob qho kev txhaj tshuaj ntawm qhov kawg ntawm lub nozzle, yog li tiv thaiv kev thaiv ntawm ceg channel lossis rooj vag. Yog tias cov khoom txias sib xyaw rau hauv cov kab noj hniav, kev ntxhov siab sab hauv tau yooj yim tsim hauv cov khoom tsim. Txoj kab uas hla ntawm lub qhov dej txias yog hais txog 8-10mm thiab qhov tob yog 6mm. Txhawm rau kom yooj yim demoulding, hauv qab feem ntau yog los ntawm tus pas nrig demoulding. Sab saum toj ntawm tus pas nrig demoulding yuav tsum tau tsim raws li ib tug zigzag nuv los yog ib tug sunken zawj, yog li ntawd lub sprue yuav rub tawm smoothly thaum demoulding.

shunt

Nws yog cov channel txuas rau lub ntsiab channel thiab txhua qhov kab noj hniav nyob rau hauv ntau qhov pwm. Txhawm rau ua kom cov yaj sau tag nrho cov kab noj hniav ntawm tib lub nrawm, kev npaj ntawm cov neeg khiav dej num ntawm cov pwm yuav tsum sib npaug thiab sib npaug. Cov duab thiab qhov luaj li cas ntawm cov ntu khiav muaj feem cuam tshuam rau qhov ntws ntawm cov yas yaj, qhov demolding ntawm cov khoom thiab qhov yooj yim ntawm pwm manufacturing. Yog hais tias qhov ntws ntawm cov khoom siv tib yam raug txiav txim siab, qhov ntws channel tsis kam nrog lub voj voog hla ntu yog qhov tsawg tshaj plaws. Txawm li cas los xij, vim tias qhov tshwj xeeb ntawm tus cylindrical khiav yog me me, nws tsis zoo rau qhov txias ntawm cov neeg khiav dej num ntau dhau, thiab tus khiav yuav tsum tau qhib rau ntawm ob sab ntawm cov pwm, uas yog kev siv zog ntau thiab nyuaj rau kev sib dhos. Yog li ntawd, cov neeg khiav dej num trapezoidal lossis semi-circular cross-section runners feem ntau siv, thiab qhib rau ntawm ib nrab ntawm cov pwm nrog ejector tuav. Cov neeg khiav dej num yuav tsum tau polished kom tsis txhob ntws tawm thiab muab kev ua kom nrawm dua. Qhov loj ntawm tus khiav yog nyob ntawm hom yas, qhov loj thiab tuab ntawm cov khoom. Rau feem ntau cov thermoplastics, qhov sib txawv ntawm qhov dav ntawm tus khiav tsis pub tshaj 8 hli, qhov loj ntxiv tuaj yeem ncav cuag 10-12mm, thiab qhov me me ntxiv yog 2-3mm. Raws li qhov ua tau raws li qhov xav tau, qhov chaw hla ntu yuav tsum raug txo kom ntau li ntau tau los ua kom cov khib nyiab shunting thiab ua kom lub sijhawm txias.

rooj vag

Nws yog cov channel uas txuas lub ntsiab channel (los yog shunt channel) thiab kab noj hniav. Qhov chaw hla ntu ntawm cov channel tuaj yeem sib npaug rau lub ntsiab channel (los yog ceg channel), tab sis feem ntau nws raug txo. Yog li ntawd, nws yog ib feem nrog qhov tsawg tshaj plaws cross-sectional cheeb tsam nyob rau hauv tag nrho cov khiav system. Cov duab thiab qhov loj ntawm lub rooj vag muaj kev cuam tshuam zoo rau qhov zoo ntawm cov khoom.

Peb lub tuam txhab:

Peb lub tuam txhab yog ib lub tuam txhab kev tsim khoom thiab kev muag khoom. Kev tshawb fawb thiab kev tsim khoom ntawm lub raj mis cap pwm rau ntau tshaj 10 xyoo, nrog rau kev tshawb fawb muaj zog technology, kev tshawb fawb thiab kev tsim kho thiab kev tsim khoom, cov khoom raug xa tawm mus rau thoob plaws lub ntiaj teb. Peb muaj high-precision CNC tshuab cuab yeej thiab machining chaw, cov cuab yeej siv siab heev thiab cov cuab yeej ntsuas, cov cuab yeej siv tau zoo thiab kev tswj hwm nruj thiab zoo meej.
